Machine features

1.Automatic Stand up Pouch Doypack Filling Packing Rapid change of the specifications of the bag,

bag width can be automatically adjusted by one button;

2.Single shaft ad the CAM design, packing speed faster, more stable operation.maintenance easier

and reduce defective rate;

3. Modular heating, more accurate temperature control, heating fault can alarm;
4. Advanced design concept, reduce the loss of packaging material, ensure the stability of the operation

of equipment,prolong the operation of equipment life;

5.simple and convenient operation, using advanced PLC+POD (touch screen)electrical control system,

man-machine interface friendly;

6.The machine has a wide range of packaging, packaging liquid, paste, powder particles, solid materials

just according to different materials to choose different metering device can be;

7.This machine USE s the prefabricated packing bag, the packing pattern is perfect,the sealing quality

is good, thus enhances the product quality and the class.

Machine parameters

Type	XLY-270D
packing material	Composite bags such as four sided sealed bags, aluminum foil bags, paper bags, zipper bags, self-supporting bags, M-shaped bags, etc
packing bag size	W:80-180mm H:160-280mm
packing speed	50-80 bag/min (The packaging speed is determined by the material type and filling weight)
dimensions（L*W*H）	3600*1320*1950mm
machine weight	1900KG
Air consumption	≥0.6m³/min(Compressed air is provided by the user)
total power	5kw

Application

Suitable for various liquids and sauces, such as tomato sauce, peanut butter, bean paste, detergent, yellow wine,

soy sauce, rice vinegar, fruit wine, etc.
