1.Servo control, automatically detect product length and cut, operator needn't to adjust the unloading
working, saving time and saving films.
2.Human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4.High sensitivity optical electric color mark tracking &digital input cut position which makes the sealing
&cutting more accurate.
5.Separate control to temperature, suitable for various packing materials.
6.Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7.Simple driving system, reliable working, convenient maintenance.
8.All the controls are achieved by software, convenient for function adjusting and upgrading.
Model | XLY-654 |
Max.film width | 260mm |
Max packaging capacity | 40-250 times/min |
Suitable film thickness | 0.03-0.06mm |
Length of bags | 65-330mm |
Packaging width | 30-100mm |
Packaging height | ≤45mm |
Total power | 2.4Kw 220V |
Overall dimensions(L x W x H) | 4000x920x1500mm |
Weight | 500kg |
1.Food: cake, bread, biscuits, cookies, meat muffin, flaky pastry, moon cake, several sausage in a
bag, noodles, beef jerky, egg roll, etc.
2.Vegetables and Fruits: apples, bananas, lettuce, potatoes, tomatoes, peppers, cucumbers, etc.
3.Daily use: plastic knife, fork, plate, sponge, scourer, wipes, several straws in a bag, gift, cups, bottles,
napkin, baby diaper,etc.
