1.The machine completes the whole procedure of filling,measuring,bagging,date printing,charging
(exhausting),product out-putting automatically.
2.High precision,high efficiency without crash the materials.
3.New design with perfect fashion, more reasonable structure, more advanced technology.
4.Imported PLC control system, colorful touch screen, easy operation, intuitionistic and efficient.
5.Standard positioning with imported servo film transporting system and mark sensor, super excellent
capability for complete machine, perfect packaging.
6.With auto warning protection function to minimize loss.
7.Various kinds of bag, it could provide the pillow bag, angle fold bag, hang hole bag, link bag, etc.
8.Automatic correct function, save time, labor and film, the operation more intelligent.
9.Adopt external film feeding mechanism. Film setting be more easy and quick.
Model | XLY-475 |
Bag Length | 50-300mm |
Front Width | 50-200mm |
Film Width | 420mm(Max.) |
Packing Speed | 30-85packet/min |
Gas Consumption | 0.45m³/min |
Air Pressure | 0.65Mpa |
Power | 220V AC 50HZ,single phase,2.2KW |
Packaging Film | Complex film |
(OPP/CPP,OPP/PE,PET/PE etc) | |
Dimension(mm) | 1600(L)×1150(W)×1480(H)mm |
Net Weight | 580KG |
All kinds of grain material, sheet material, strip material and abnormity material which such as candy,
melon seeds, chips, peanut, nutlet, preserved fruit, jelly, biscuit, confect, camphorball, currant, almond,
chocolate, filbert, corn, Potato Crisps, pet foodstuff, dilatant foodstuff, hardware and plastic can be
weighed by the ration.
